5 Wires Narrow Electric Bolt Lock

5 Wires Narrow Electric Bolt Lock
5 Wires Narrow Electric Bolt Lock - Image 2

5 Wires Narrow Electric Bolt Lock

Tortor posuere ac ut consequat semper viverra nam. Sed viverra tellus in hac habitasse. Cras tincidunt lobortis feugiat vivamus at augue eget amet.

Brand: Avecone

Item No.: ED100

Inquiry

Description

What is Electromagnetic Lock? Electromagnetic locks consist of an armature and a coil assembly, which become magnetized when an electric current passes through them. This magnetic field secures the door and electronically controls when doors are locked and unlocked. Electromagnetic locks are fail-safe by design.

Additional information

Lock Size

250 X 48.5 X 25 MM

Plate

180 X 38 X 11 MM

Holding Force

280KG (600LBS)

Voltage

DC12V or DC24V

Current Draw

12V/500mA 24V/250mA

Signal Output

Dry Contact, Max Rating of Contact Current 3A

Surface Temperature

≤20°C

Operating Temperature

-10°C ~ 55°C

Suitable Humidity

0~90% (non-condensing)

Finishes for Shell

Anodized Aluminium Surface Texture Processing

Weight

2KG
